370z / G37

Nissan 370z Z34 / Infiniti G37 V36 Chassis

2008–2020

The Nissan 370z and Infiniti G37 share the Z34/V36 platform and are powered by the VQ37VHR engine. The 370z NISMO variant features a factory Torsen LSD and upgraded suspension components. These platforms are gaining popularity in drifting due to their modern chassis dynamics and strong engine output.

Nissan 370z Z34 (2008–2020)Infiniti G37 Coupe V36 (2007–2013)Infiniti G37 Sedan V36 (2007–2013)
370z / G37
Display Units:
Basic — first 5 specs per section

Always verify torque specifications with your specific year/model OEM service manual before assembly. Values shown are reference specifications and may vary by model year, revision, or regional market.

SuspensionDrivetrainBrakesSteering

1Suspension

9 specifications · 4 locked

Suspension
ComponentValueUnitNotes
Front Lower Control Arm Bolts87–116lb-ft
Front Upper Control Arm Bolts58–72lb-ft
Front Strut to Knuckle Pinch Bolt72–87lb-ft
Front Strut Top Mount Nuts29–40lb-ft
Front Sway Bar Bracket22–29lb-ft
██████████████████████████████████
██████████████████████████████████
██████████████████████████████████

4 more specs locked

Upgrade to Pro to unlock all torque specs

2Drivetrain

5 specifications

Drivetrain
ComponentValueUnitNotes
Motor Mount Bolts43–58lb-ft
Transmission Mount Bolts29–40lb-ft
Propeller Shaft to Diff Flange29–36lb-ft
Differential Mounting Bolts72–87lb-ft
Rear Axle Nut152–203lb-ft

3Brakes

3 specifications

Brakes
ComponentValueUnitNotes
Front Brake Caliper Bolts101–116lb-ft
Rear Brake Caliper Bolts43–58lb-ft
Lug Nuts72–87lb-ft

4Steering

2 specifications

Steering
ComponentValueUnitNotes
Steering Rack Mounting Bolts58–72lb-ft
Tie Rod End to Knuckle22–29lb-ft
